  • Dimensions: 36.2 x 15.4 x 3 cm
    Functions:
    Display: LED
    LED color: Red
    Time format: 12 – 24 H – HOUR – MINUTES – SECONDS
    Date: Up to 50 years, DATE – MONTH – YEAR
    Temperature: -9°C to +50°C
    Alarm: Yes
    Adjustable brightness: From 22:00 to 07:00
    Clock power supply: 5V – 1A DC

    Power adapter input: 100-240V AC – 50/60Hz
    Output: 5V – 1A, DC plug 2.1 x 5.5 mm

    Package includes:

    • 1 Digital Clock
    • 1 Power adapter with USB output
    • 1 USB to DC cable (2.1 x 5.5 mm)
  • Instructions for use:

    1. Installation: Unpack, connect to a 220V/50Hz outlet, and set the display to synchronize with the current hour, minutes, seconds, AM/PM, day, month, year, week, and temperature.
    2. Clock and calendar setup: Press the „adjust“ button once. The LED for the year will start flashing. Press „change year“ to set the year. Then press „adjust“ to modify the month, day, hour, minutes, and seconds accordingly.
      Press „adjust“ again to enter alarm setting mode. When LED 1 flashes, it means it’s time to set the alarm. Press „change“ to select the alarm number, then „adjust“ to make the hour LED blink and set it. Press „change“ again to make the minute LED blink and adjust the minutes. Do the same for the month. Finally, press „change“ to activate the alarm. Press „adjust“ again to return to the normal display.
    3. If the „change“ and „adjust“ buttons are not used during the setup process, the settings cannot be made.
    4. During the date, week, and month setup process, these values will update automatically.
    5. In case of a power outage, if the date and time display is incorrect (e.g., shows „July 2001“), unplug the power cable, replace the battery, plug it back in, and reset the date, time, and alarm.
    6. Time setting: Press the „adjust“ button and the hour LED will flash. Use the „change“ button to adjust the hour. If it goes beyond 11 AM, PM will be selected, and you can enter the 24-hour format after 11 PM. If you’re in a menu option you don’t want, press the „exit“ button to return to the normal display.

      Warning: Pressing the „reset“ button will erase all saved settings.
